Automatic reset, open on rise (normally closed) or close on rise (normally open)
Single pole, single throw (SPST)
Cost effective, compact, high reliability, long life, ROHS compliant
Water-proof construction
Specifications
Operating temperature range: 0～150℃ (32～302°F)
Temperature differentials : 8.5～55 K (difference between nominal off and on temperatures)
Temperature tolerance: ±3.0K, ±5.0K
Contact rContact resistance: 50mΩor less
Electrical Rating:
Electrical rating | Agency approvals | |||||
VDE | UL | TÚV | CQC | Life cycles | Remarks | |
AC125V/10A | ● | 100 K | Phenolic housing | |||
AC125V/16A | ● | 100 K | ||||
AC250V/10A | ● | ● | 100 K | |||
AC250V/16A | ● | ● | 100 K | |||
